Specialized ginger candy pillow packing machine with disc feeding system. Gentle handling for crystallized and soft ginger candy. CE certified, food-grade 304 stainless steel.
The Junyao ginger candy pillow packing machine addresses these specifics with a disc feeding system that singulates individual pieces and a wrapping platform tuned for ginger candy's unique handling requirements.
The disc feeder uses rotating pockets sized to your ginger candy dimensions to pick up one piece at a time from the bulk product supply. Each pocket carries an individual candy to the transfer point where it's handed off to the wrapping station — no product-to-product contact, no clumping, no sticky transfer. The disc surface is treated with a food-grade anti-stick coating that prevents sugar residue buildup.
1. Disc feeding system — solves the clumping problem. Rotating disc with custom-sized pockets picks individual pieces. Anti-stick coating prevents sugar residue transfer. Adjustable disc speed synchronized with wrapping speed via servo control.
2. Gentle product handling. Pocket geometry matches your ginger candy profile — no crushing, no chipping. Products transfer from disc to wrapping station via a short, smooth guide channel.
3. Temperature-controlled sealing for sugary surfaces. Ginger candy's surface sugar can caramelize on hot sealing jaws, causing film sticking and seal defects. This machine's PID temperature control and non-stick jaw coating prevent this, maintaining clean seals throughout extended production runs.
4. Quick-clean design. The disc feeder lifts off without tools for end-of-shift cleaning. Guide channels are smooth 304 stainless steel with no hidden corners.
5. Recipe memory for multiple ginger candy formats. Store disc speed, wrapping speed, sealing temperature, and film length for each candy size and format.
| Parameter | Value |
| Model | JY-ZB1200GB |
| Packaging Speed | 100 - 800 packs/min |
| Power | 4.5 KW |
| Weight | 850 KG |
| Dimensions (L × W × H) | 2500 × 1350 × 1600 mm |
| Bag Size Range | 40 - 130 mm |
| Film Width | Up to 300 mm |
| Feeding Method | Rotary disc feeding |
| Control System | Schneider servo + PLC + SICK sensor |
| HMI Interface | 7-inch color touch screen, multi-language |
| Power Supply | 220V / 50-60Hz (customizable) |
| Certification | CE |
Xingjunyao Intelligent Packaging Technology (Taizhou) Co., Ltd. manufactures the JY-L600 at its 13,000 m² factory in Taizhou, Zhejiang, China. Founded in 2014 and employing approximately 100 people, the company has built a production system that combines CNC machining centers, laser cutting, and precision assembly lines under one roof. Critical components such as the disc feeder, sealing jaws, and servo frames are produced in-house to maintain dimensional control and interchangeability across production batches.
